600W Solar Panel

Model Number：	RSM600-120HC
Cell Orientation：	120cells(6*20)
Weight：	29.0kg
Brand Name：	Rosen Solar
Size：	2172 130335mm
J-Box：	IP68 rated
Solar cell：	Monocrystalline, 210mm
Warranty：	25 year Power Warranty
Backsheet：	White
Glass：	3.2mm, High Transparency solar glass
PV Cable：	Portrait: 280/280mm; Landscape: 1400/1400mm; 4mm²
Connector：	MC4 EVO2/TS4*
Frame：	Silver, Anodized Aluminium Alloy
Encapsulant Material：	EVA/POE

Send a message

Detail

Rosen Solar is professional manufacturer of solar panel.

Monocrystalline 120cells Solar Panel.

Power Range : 585~605W

mono 550w solar panel.jpg

Technical Specification Data(STC) of Solar Panel:

Model	RSM585-120 HC	RSM590-120 HC	RSM595-120HC	RSM600-120 HC	RSM605-120 HC
Rated Maximum Power at STC	585W	590W	595W	600W	605W
Open Circuit Voltage(Voc)	49.60	49.75	49.90	50.05	50.20
Maximum Power Voltage(Vmp)	41.64	41.80	41.96	42.12	42.28
Short Circuit Current(Isc)	13.86	13.93	14.00	14.07	14.14
Maximum Power Current(Imp)	12.97	13.04	13.11	13.18	13.25
Module Efficiency(%)	21.1	21.3	21.5	21.7	21.9
Standard Test Condition(STC)	Irradiance 1000w/m2, Cell Temperature 25°C, Air Mass 1.5

10bb solar panel.png

Detailed Images of Solar Panel:

Packaging & delivery:

Packing Details : In carton on pallet or wooden box

Delivery Details : 5-10 working days

half cell solar panel.jpg
