0.2C to 29.2V, then 29.2V,charge current to 0.02C (CC/CV)
Charger Current
20A
Max. Charge Current
40A
Charge Cut-off Voltage
29.2±0.2V
Discharge Data
Continuous Current
50A
Max continuous discharge current
100A
Discharge Cut-off Voltage
16V
Working Condition
Charge Temperature
0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity
Discharge Temperature
-20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity
Storage Temperature
-10℃ to 45℃ (32℉ to 104℉) @60±25% Relative Humidity
Enclosure Protection Level
IP20
Mechanical Data
Cell & Method
3.2V100Ah
Shell material
Iron
Dimensions
520*180*230mm
Weight (lbs./kg.)
27kgs
Battery Application
Application
♦Wheelchairs and scooters ♦Solar/wind energy storage ♦Back-up power for small UPS ♦Golf trolleys & buggies ♦Electric bikes
Key Features ♦Longer Cycle Life : Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership ♦Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries ♦Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity ♦Wider Temperature Range : -20℃~60℃ ♦Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation
Assembly Details
Package and Delivery
