10Kwh Lithium Battery 48V

Model Number：	LFP48V200AH
Weight：	108kgs
Brand Name：	LifePO4 Lithium Battery Pack
Size：	680495185mm
Color：	Gray/Black/ Red/White
Warranty：	10 years
Certificate：	CE/ROSH/MSDS/UN38.3/IEC/ISO9001/ISO14001
Application：	Home Appliances, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
Battery Type：	LifePO4 Lithium Battery Pack
inverter：	Solax, Goodwe, Growatt, Victron, Sofar, GMDE, etc.
Usage：	Car, Bus, UPS, Electric Power, Lighting, Electric Bicycle, Boat
Packing：	Wooden Box / Carton Packing
Voltage：	48V

Send a message

Detail

Technical Specification

Type	Module	Powerwall
Model	LFP48V50AH	LFP48V100AH	LFP48V150AH	LFP48V200AH
Battery Capacity [Ah]	50Ah	100Ah	150Ah	200Ah
Nominal Battery Energy [kwh]	2.4	4.8	7.2	9.6
Max Discharge Current [A]	50	100	150	200
Net Weight	35	68	95	108
Dimension [HWD, mm]	44248088	680495185	680495185	680495185
Operating Temperature Range	-20 ~ 50 [℃ ]
Life Cycles	>6000
Nominal Voltage [V]	48Vdc
Communication	CAN/RS485/DRY CONTACT
Certificate & Safety Standard	TUV / CE / EN62619 / IEC62040 / UN38.3
Warranty	10 Years
Alarms	Battery Operation/Out of Battery/System fault
Pros	Applied in off-grid and hybrid system, Compact Design, Modular Expansion
Monitoring & Protection	With BMS protection in each Module, and breaker embedded in the system
